Charcoal Briquetting Machine

CHARCOAL BRIQUETTING MACHINE

Detailed content
Leave A Message

[Production Capacity: 4-18 t/h]

[Briquette size: 25-75mm or customized]

[Feeding Material Size: Less than 3mm]

Welcome To FTM. Scrolls Are Cheap.
X

Send Inquiry

Introduction

Charcoal briquetting machine is mainly used to suppress powdery materials that are difficult to form. Charcoal briquetting machine is widely used in power plants, metallurgy, refractory material, chemical, energy, transportation, heating, animal husbandry, industrial, agricultural, barbecue and other fields. Charcoal briquetting machine can produce square shape, ball type, round, oval, round type, pillow type and other special shaped materials.

Charcoal Briquetting Machine

Related products

Highlight Advantages

Charcoal briquetting machine is characterized by large molding pressure, adjustable number of revolutions of the main engine, and a screw feeding device.

Charcoal briquetting machine is mainly used for:

carbon powder forming, pulverized coal forming; dry powder forming; desulfurization gypsum molding; coke powder molding; iron filings.

Send Inquiry

Technical data

Model Roll diamter
(mm)
Roll width
(mm)
Total pressure
(t)
Main motor power
(kw)
Output
(t)
Weight
(t)
GY520-150 520 196 150 55 2.2-3.5 13
GY650-220 650 200 220 110 4-6.5 19.2
GY750-300 750 280 300 185 6-8.5 34
GY1000-350 1000 440 350 250 10-15 50.8
GY1000-450 1000 504 450 280 14-17 58.5
GY1000-500 1000 504 500 315 15-20 58.5
GYS1000-500 1000 600 500 280 17-21 56.5
GY1000-540 1000 900 540 185Kw×2 30-35 60
GY1200-800 1200 900 800 280Kw×2 40 110
GY1400-1000 1400 1000 1000 400Kw×2 50 156
Model Roll diamter
(mm)
Roll width
(mm)
Total pressure
(t)
GY520-150 520 196 150
GY650-220 650 200 220
GY750-300 750 280 300
GY1000-350 1000 440 350
GY1000-450 1000 504 450
GY1000-500 1000 504 500
GYS1000-500 1000 600 500
GY1000-540 1000 900 540
GY1200-800 1200 900 800
GY1400-1000 1400 1000 1000

Note:Processing Capacity May Vary With Different materials and Feeding Sizes.
